Aruba Access Points

Aruba access points (APs) offer maximum deployment flexibility in a wide range of wireless LAN (WLAN) environments — central and remote sites, locations with high concentrations of Wi-Fi clients, indoors and outdoors, and harsh industrial environments.

Working with Aruba Mobility Controllers, these centrally managed single- and multi-radio APs provide zero-touch configuration and automatic software updates. Multifunctional Aruba APs perform spectrum analysis to mitigate Wi-Fi interference, air monitoring to ensure wireless security, and operate as Remote APs (RAPs) or as part of a secure enterprise mesh.

Enterprise-grade Wi-Fi Access Points

Aruba 802.11ac wireless access points deliver superb Wi-Fi performance – they can be deployed as controller-managed or controllerless Aruba Instant APs depending on the design, scope and scale of your wireless network. And our newest Wave 2 APs deliver screaming fast 11ac speeds with a HPE Smart Rate multi-gig uplink to boost network performance in high-density environments.

Indoor Wireless:

AP-103

AP-103

Low-density 802.11n

  • Two integrated dual-band down-tilt omni-directional antennas
  • For low-density Wi-Fi environments
  • 2x2 MIMO, two spatial streams, up to 300 Mbps
  • 2.4- and 5-GHz radios
  • Two internal antennas per radio
  • Mounts on ceiling or wall

AP-204

AP-204

Most popular 802.11ac

  • Two combined, diplexed external RP-SMA antenna connectors
  • Top performance in mediumdensity environments
  • 2x2 MIMO, two spatial streams, up to 867 Mbps
  • 2.4- and 5-GHz radios
  • Internal and external antenna options
  • Mounts on ceiling or wall

AP-205

AP-205

Most popular 802.11ac

  • Four integrated omni-directional downtilt antennas
  • Top performance in mediumdensity environments
  • 2x2 MIMO, two spatial streams, up to 867 Mbps
  • 2.4- and 5-GHz radios
  • Internal and external antenna options
  • Mounts on ceiling or wall

AP-207

AP-207

Low-cost 802.11ac

  • Two integrated omni-directional downtilt dualband antennas
  • 2x2 MIMO, two spatial streams, up to 867 Mbps
  • 2.4- and 5-GHz radios
  • Internal and external antenna options
  • Mount on wall or ceiling

AP-214

AP-214

High-performance 802.11ac

  • Three combined, diplexed (dual-band) external RP-SMA antenna connectors
  • For medium-density Wi-Fi environments
  • 3x3 MIMO, three spatial streams, up to 1.3 Gbps
  • 2.4- and 5-GHz radios
  • Internal and external antenna options
  • Mounts on ceiling or wall

AP-215

AP-215

High-performance 802.11ac

  • Six integrated omni-directional downtilt antennas
  • For medium-density Wi-Fi environments
  • 3x3 MIMO, three spatial streams, up to 1.3 Gbps
  • 2.4- and 5-GHz radios
  • Internal and external antenna options
  • Mounts on ceiling or wall

AP-224

AP-224

Top performing 802.11ac

  • Three combined, diplexed external antenna connectors
  • For extremely high-density client environments
  • 3x3 MIMO, three spatial streams, up to 1.3 Gbps
  • 2.4- and 5-GHz radios
  • Internal and external antenna options
  • Mounts on ceiling or wall

AP-225

AP-225

Top performing 802.11ac

  • Three integrated omni-directional downtilt antennas
  • For extremely high-density client environments
  • 3x3 MIMO, three spatial streams, up to 1.3 Gbps
  • 2.4- and 5-GHz radios
  • Internal and external antenna options
  • Mounts on ceiling or wall

AP-228

AP-228

802.11ac for Rugged Indoor Environments

  • Three combined, diplexed external antenna connectors
  • 3x3 MIMO, three spatial streams, up to 1.3 Mbps
  • 2.4- and 5-GHz radios
  • Six connectors for external antennas
  • Mounts on ceiling or wall

AP-304

AP-304

Entry-level 802.11ac Wave 2

  • Three dual-band RP-SMA connectors for external antennas
  • 3x3 MIMO, four spatial streams, up to 1,300 Mbps
  • 2x2 MIMO, two spatial streams, up to 400 Mbps
  • Internal and external antenna options
  • Mount on wall or ceiling

AP-305

AP-305

Entry-level 802.11ac Wave 2

  • Three integrated omni-directional downtilt dualband antennas
  • 3x3 MIMO, four spatial streams, up to 1,300 Mbps
  • 2x2 MIMO, two spatial streams, up to 400 Mbps
  • Internal and external antenna options
  • Mount on wall or ceiling

AP-314

AP-314

Popular 802.11ac Wave 2

  • Four dual-band RP-SMA connectors for external antennas
  • 4x4, 4 spatial streams Multi-user MIMO in 5Ghz, up to 1,733 Mbps
  • 2x2, 2 spatial streams SU-MIMO in 2.4Ghz, up to 400 Mbps
  • Built-in BLE radio
  • Internal and external antennas
  • Mount on wall or ceiling

AP-315

AP-315

Popular 802.11ac Wave 2

  • Four integrated omni-directional downtilt dual-band antennas
  • 4x4, 4 spatial streams Multi-user MIMO in 5Ghz, up to 1,733 Mbps
  • 2x2, 2 spatial streams SU-MIMO in 2.4Ghz, up to 400 Mbps
  • Built-in BLE radio
  • Internal and external antennas
  • Mount on wall or ceiling

AP-324

AP-324

High performance 802.11ac Wave 2

  • Four combined, diplexed (dual-band) external RP-SMA antenna connectors
  • Top performance and efficiency in high density client environments
  • 4x4 MIMO, four spatial streams, up to 1,733 Mbps
  • Multi-user MIMO
  • 2.4- and 5GHz radios
  • Built-in BLE radio
  • Internal and external antenna options

AP-325

AP-325

High performance 802.11ac Wave 2

  • Eight integrated omni-directional downtilt antennas
  • Top performance and efficiency in high density client environments
  • 4x4 MIMO, four spatial streams, up to 1,733 Mbps
  • Multi-user MIMO
  • 2.4- and 5GHz radios
  • Built-in BLE radio
  • Internal and external antenna options

AP-334

AP-334

Multi-gigabit 802.11ac Wave 2 with HPE Smart Rate

  • Four combined, diplexed (dual-band) external RP-SMA antenna connectors
  • Provide fastest gigabit data speeds and superb user experience for mobile devices and applications
  • HPE Smart Rate uplink port that scales up to 5Gbps
  • 4X4 MIMO, four spatial streams up to 1,733Mbps
  • Multi-user MIMO
  • 2.4- and 5Ghz radios
  • Built-in Bluetooth Low Energy (BLE) radio
  • Internal and external antenna options
  • Mount on ceiling or wall

AP-335

AP-335

Multi-gigabit 802.11ac Wave 2 with HPE Smart Rate

  • Eight integrated omni-directional downtilt antennas
  • Provide fastest gigabit data speeds and superb user experience for mobile devices and applications
  • HPE Smart Rate uplink port that scales up to 5Gbps
  • 4X4 MIMO, four spatial streams up to 1,733Mbps
  • Multi-user MIMO
  • 2.4- and 5Ghz radios
  • Built-in Bluetooth Low Energy (BLE) radio
  • Internal and external antenna options
  • Mount on ceiling or wall
Desk Stand and Wall Plate:

AP-103H

AP-103H

Controller-Managed, Wall-Mount 802.11n

  • 2x2 MIMO, two spatial streams, up to 300 Mbps
  • 2.4- and 5-GHz radios
  • Two integrated dual-band omni-directional antennas
  • Two ports to connect wired devices
  • Mounts on wall-box

AP-205H

AP-205H

802.11ac for Hospitality and Branch

  • 2x2 MIMO, two spatial streams, up to 867 Mbps
  • 2.4- and 5-GHz radios
  • Four integrated semi-directional antennas
  • Three ports to connect wired devices
  • Optional 3G/4G WAN connection
  • Sits on your desk or mounts on wall-box
Outdoor Wireless:

AP-274

AP-274

Outdoor 802.11ac

  • Three integrated omni-directional antennas
  • 2.4- and 5-GHz radios
  • 3x3 MIMO, three spatial streams, up to 1.3 Gbps
  • Internal and external antenna options
  • Mounts on a pole or building

AP-275

AP-275

Outdoor 802.11ac

  • Three external antenna connectors
  • 2.4- and 5-GHz radios
  • 3x3 MIMO, three spatial streams, up to 1.3 Gbps
  • Internal and external antenna options
  • Mounts on a pole or building

AP-277

AP-277

Outdoor 802.11ac

  • Three integrated 80° H x 80° V beamwidth directional antennas
  • 2.4- and 5-GHz radios
  • 3x3 MIMO, three spatial streams, up to 1.3 Gbps
  • Internal and external antenna options
  • Mounts on a pole or building

Remote Access Points

Aruba 802.11n Remote Access Points (RAPs) provide secure always-on network access to corporate enterprise resources from remote locations. Ideal for users in small branch offices and teleworkers in home offices, Aruba RAPs support wired and wireless connectivity, traffic forwarding traffic based on policy, user-centric security, and backup links over cellular networks.

Remote Access Points:

RAP-3

RAP-3

Telecommuter 802.11n

  • One 2.4-GHz radio
  • 2x2 MIMO, up to 300 Mbps
  • Two ports to connect wired devices
  • Optional 3G/4G WAN connection
  • Sits on your desk

RAP-108 and 109

RAP-108 and 109 Series

Home and branch 802.11n

  • 2.4- and 5-GHz radios
  • 2x2 MIMO, up to 300 Mbps
  • One port to connect wired devices
  • Optional 3G/4G WAN connection
  • Sits on your desk

RAP-155

RAP-155

Branch office 802.11n

  • 2.4- and 5-GHz radios
  • 3x3 MIMO, three spatial streams, up to 450 Mbps, 100 Mbps encrypted throughput
  • Four ports to connect wired devices (optional power-over-Ethernet on two ports)
  • Optional 3G/4G WAN connection
  • Sits on your desk

Indoor and Outdoor Antennas

Indoor and outdoor antennas are designed for coverage applications to increase signal reception in a variety of environments. Aruba indoor and outdoor antennas accommodate a variety of requirements.
