Aruba Instant Wi-Fi Access Points
Up to 10x Faster Wi-Fi


Aruba Instant Wi-Fi Access Points

Everything about Aruba Instant controller-less Wi-Fi is fast – fast network setup, fast maintenance and upgrades – and most important, super-fast client experience.

Aruba Instant virtualizes Aruba Mobility Controller capabilities on 802.11n access points (AP), creating a feature-rich enterprise-grade wireless LAN (WLAN) that delivers the affordability and simplicity of an entry-level Wi-Fi network.

Indoor Wireless:

IAP-204

IAP-204

Most popular 802.11ac

  • Two combined, diplexed external RP-SMA antenna connectors
  • Top performance in mediumdensity environments
  • 2x2 MIMO, two spatial streams, up to 867 Mbps
  • 2.4- and 5-GHz radios
  • Internal and external antenna options
  • Mounts on ceiling or wall

IAP-205

IAP-205

Most popular 802.11ac

  • Four integrated omni-directional downtilt antennas
  • Top performance in mediumdensity environments
  • 2x2 MIMO, two spatial streams, up to 867 Mbps
  • 2.4- and 5-GHz radios
  • Internal and external antenna options
  • Mounts on ceiling or wall

IAP-214

IAP-214

High-performance 802.11ac

  • Three combined, diplexed (dual-band) external RP-SMA antenna connectors
  • For medium-density Wi-Fi environments
  • 3x3 MIMO, three spatial streams, up to 1.3 Gbps
  • 2.4- and 5-GHz radios
  • Internal and external antenna options
  • Mounts on ceiling or wall

IAP-215

IAP-215

High-performance 802.11ac

  • Six integrated omni-directional downtilt antennas
  • For medium-density Wi-Fi environments
  • 3x3 MIMO, three spatial streams, up to 1.3 Gbps
  • 2.4- and 5-GHz radios
  • Internal and external antenna options
  • Mounts on ceiling or wall

IAP-224

IAP-224

Top performing 802.11ac

  • Three combined, diplexed external antenna connectors
  • For extremely high-density client environments
  • 3x3 MIMO, three spatial streams, up to 1.3 Gbps
  • 2.4- and 5-GHz radios
  • Internal and external antenna options
  • Mounts on ceiling or wall

IAP-225

IAP-225

Top performing 802.11ac

  • Three integrated omni-directional downtilt antennas
  • For extremely high-density client environments
  • 3x3 MIMO, three spatial streams, up to 1.3 Gbps
  • 2.4- and 5-GHz radios
  • Internal and external antenna options
  • Mounts on ceiling or wall

IAP-228

IAP-228

802.11ac for Rugged Indoor Environments

  • Three combined, diplexed external antenna connectors
  • 3x3 MIMO, three spatial streams, up to 1.3 Mbps
  • 2.4- and 5-GHz radios
  • Six connectors for external antennas
  • Mounts on ceiling or wall

IAP-304

IAP-304

Popular 802.11ac

  • 5GHz 3x3 MIMO (1,300 Mbps max rate)
  • 2.4GHz 2x2 MIMO (400 Mbps max rate) radios
  • 3x3:3SS MU-MIMO capability
  • three dual-band RP-SMA connectors
  • external antennas

IAP-305

IAP-305

Popular 802.11ac

  • 5GHz 3x3 MIMO (1,300 Mbps max rate)
  • 2.4GHz 2x2 MIMO (400 Mbps max rate) radios
  • Built-in BLE radio
  • three integrated omni-directional downtilt dualband antennas

IAP-314

IAP-314

Popular 802.11ac Wave 2

  • Four dual-band RP-SMA connectors for external antennas
  • 4x4, 4 spatial streams Multi-user MIMO in 5Ghz, up to 1,733 Mbps
  • 2x2, 2 spatial streams SU-MIMO in 2.4Ghz, up to 400 Mbps
  • Built-in BLE radio
  • Internal and external antennas
  • Mount on wall or ceiling

IAP-315

IAP-315

Popular 802.11ac Wave 2

  • Four integrated omni-directional downtilt dual-band antennas
  • 4x4, 4 spatial streams Multi-user MIMO in 5Ghz, up to 1,733 Mbps
  • 2x2, 2 spatial streams SU-MIMO in 2.4Ghz, up to 400 Mbps
  • Built-in BLE radio
  • Internal and external antennas
  • Mount on wall or ceiling

IAP-324

IAP-324

High performance 802.11ac Wave 2

  • Four combined, diplexed (dual-band) external RP-SMA antenna connectors
  • Top performance and efficiency in high density client environments
  • 4x4 MIMO, four spatial streams, up to 1,733 Mbps
  • Multi-user MIMO
  • 2.4- and 5GHz radios
  • Built-in BLE radio
  • Internal and external antenna options

IAP-325

IAP-325

High performance 802.11ac Wave 2

  • Eight integrated omni-directional downtilt antennas
  • Top performance and efficiency in high density client environments
  • 4x4 MIMO, four spatial streams, up to 1,733 Mbps
  • Multi-user MIMO
  • 2.4- and 5GHz radios
  • Built-in BLE radio
  • Internal and external antenna options

IAP-334

IAP-334

Multi-gigabit 802.11ac Wave 2 with HPE Smart Rate

  • Four combined, diplexed (dual-band) external RP-SMA antenna connectors
  • Provide fastest gigabit data speeds and superb user experience for mobile devices and applications
  • HPE Smart Rate uplink port that scales up to 5Gbps
  • 4X4 MIMO, four spatial streams up to 1,733Mbps
  • Multi-user MIMO
  • 2.4- and 5Ghz radios
  • Built-in Bluetooth Low Energy (BLE) radio
  • Internal and external antenna options
  • Mount on ceiling or wall

IAP-335

IAP-335

Multi-gigabit 802.11ac Wave 2 with HPE Smart Rate

  • Eight integrated omni-directional downtilt antennas
  • Provide fastest gigabit data speeds and superb user experience for mobile devices and applications
  • HPE Smart Rate uplink port that scales up to 5Gbps
  • 4X4 MIMO, four spatial streams up to 1,733Mbps
  • Multi-user MIMO
  • 2.4- and 5Ghz radios
  • Built-in Bluetooth Low Energy (BLE) radio
  • Internal and external antenna options
  • Mount on ceiling or wall
Desk Stand and Wall Plate:

IAP-205H

IAP-205H

802.11ac for Hospitality and Branch

  • 2x2 MIMO, two spatial streams, up to 867 Mbps
  • 2.4- and 5-GHz radios
  • Four integrated semi-directional antennas
  • Three ports to connect wired devices
  • Optional 3G/4G WAN connection
  • Sits on your desk or mounts on wall-box
Outdoor Wireless:

IAP-274

IAP-274

Outdoor 802.11ac

  • Three integrated omni-directional antennas
  • 2.4- and 5-GHz radios
  • 3x3 MIMO, three spatial streams, up to 1.3 Gbps
  • Internal and external antenna options
  • Mounts on a pole or building

IAP-275

IAP-275

Outdoor 802.11ac

  • Three external antenna connectors
  • 2.4- and 5-GHz radios
  • 3x3 MIMO, three spatial streams, up to 1.3 Gbps
  • Internal and external antenna options
  • Mounts on a pole or building

IAP-277

AP-277

Outdoor 802.11ac

  • Three integrated 80° H x 80° V beamwidth directional antennas
  • 2.4- and 5-GHz radios
  • 3x3 MIMO, three spatial streams, up to 1.3 Gbps
  • Internal and external antenna options
  • Mounts on a pole or building
