Aruba AP-514 Access Point
High performance 802.11ax enterprise access points for campus deployments

WiFi-6-icon
Aruba AP-510 Access Point
Aruba Networks Products
Aruba Wireless Access Point
Aruba AP-514 Wireless Access Point
#Q9H58A
List Price: $1,486.00
Our Price: $939.91
Aruba AP-514 Wireless Access Point
#Q9H68A
List Price: $1,757.00
Our Price: $1,276.78

Click here to jump to more pricing!

Overview:

The Aruba 510 series campus access points with 802.11ax technology are designed to deliver high performance access for mobile and (IOT) devices in environments where density is an issue. The 510 series uses 802.11ax features to efficiently and simultaneously serve multiple clients and traffic types in dense environments, increasing data rates for both individual device and overall system.

The 510 series support all mandatory and several optional 802.11ax features, which includes up- and downlink OFDMA* with up to 16 resource units, multi-user MIMO (MU-MIMO)*, 4x4 MIMO with up to four spatial streams in 5GHz and 2x2 with up to two special streams in 2.4GHz, channel bandwidths up to 160MHz (5GHz; 40MHz in 2.4GHz), and 1024-QAM modulation.

The 510 series supports maximum data rates of 4.8Gbps in the 5GHz band and 575Mbps in the 2.4GHz band (for an aggregate peak data rate of 5.4Gbps). Each AP supports up to 256 associated client devices per radio (typical recommended limit for active clients is 150), making the mid-range 802.11ax 510 series APs ideal for high density environments, such as schools, retail branches, hotels and enterprise offices.

In addition to 802.11ax standard capabilities, the 510 Series supports unique features like Aruba ClientMatch radio management and additional radios for location services and IoT applications. This delivers an unsurpassed user experience in today’s all-wireless digital work environment and offers up to 4x higher capacity in a cost-effective manner.

  • High performance Dual Radio 802.11ax AP with OFDMA and Multi-User MIMO (MU-MIMO)
  • Supports all mandatory and several optional 802.11ax features
  • Maximum data rates of 4.8Gbps in the 5GHz band and 575Mbps in the 2.4GHz band (for an aggregate peak data rate of 5.4Gbps)
  • Mid-range 802.11ax 510 series APs ideal for high density environments, such as schools, retail branches, hotels and enterprise offices
  • Includes Bluetooth 5 and Zigbee radios for location and IoT use-case

Pricing Notes:

Aruba Networks Products
Aruba Wireless Access Point
Aruba AP-514 Wireless Access Point
#Q9H58A
List Price: $1,486.00
Our Price: $939.91
Aruba AP-514 Wireless Access Point
#Q9H68A
List Price: $1,757.00
Our Price: $1,276.78
Mounting Kit
Aruba AP-MNT-MP10-A Campus AP mount bracket kit (10-pack) type A: suspended ceiling rail, flat 9/16
#JZ370A
List Price: $241.00
Our Price: $175.13
Aruba AP-MNT-MP10-B Campus AP mount bracket kit (10-pack) type B: suspended ceiling rail, flat 15/16
#Q9G69A
List Price: $241.00
Our Price: $174.17
Aruba AP-MNT-MP10-C Campus AP mount bracket kit (10-pack) type C: suspended ceiling rail, profile 9/16
#Q9G70A
List Price: $241.00
Our Price: $175.13
Aruba AP-MNT-MP10-E Campus AP mount bracket kit (10-pack) type E: wall-box
#R1C72A
List Price: $364.00
Our Price: $263.06
Aruba Wireless Access Point
Aruba Indoor Antennas
#JW009A
List Price: $37.00
Our Price: $26.89
AP-ANT-13B 2.4/5G 4/3dBi Omni
#JW001A
List Price: $173.00
Our Price: $125.72
AP-ANT-19 2.4/5G 3/6dBi Omni
#JW004A
List Price: $185.00
Our Price: $134.45
Aruba Indoor Antennas
#JW011A
List Price: $25.00
Our Price: $18.17
AP-ANT-40 2.4/5G 4/4dBi 4x4 Omni
#JW017A
List Price: $555.00
Our Price: $403.32
AP-ANT-45 2.4/5G 5dBi 4x4 Panel
#JW018A
List Price: $555.00
Our Price: $403.32
AP-ANT-48 2.4/5G 8.5dBi 4x4 Panel
#JW019A
List Price: $555.00
Our Price: $403.32
AP-ANT-MNT-4 Antenna Mount
#JW021A
List Price: $130.00
Our Price: $94.47
AP-ANT-MNT-5 Antenna Mount
#JW022A
List Price: $130.00
Our Price: $94.47
Aruba Wireless Power Accesories
PD-9001GR-AC 30W 802.3at PoE+ 10/100/1000 Ethernet Indoor Rated Midspan Injector
Includes US Power Cord
#JW629A#ABA
List Price: $155.00
Our Price: $104.01
Aruba AC Power Cord
#JW124A
List Price: $7.00
Our Price: $5.06
Aruba AP-CBL-SERU Micro-USB TTL3.3V to USB2.0 AP Console Adapter Cable
#JY728A
List Price: $32.00
Our Price: $23.13
